12 MONTHS WARRANTY
The TIG-160/200D is designed for the enthusiast wanting the benefits of TIG welding steel and stainless without the cost of an AC inverter.The TIG-160/200D is one of the easiest TIGs on the market for set up and use and also includes the most features. A must for anyone wanting to get started in TIG welding!
Technical Parameters
| Model | TIG160D-110V | TIG160D-220V | TIG200D-110V | TIG200D-220V | ||||
| Rated Input Voltage | 1P 110V | 1P 220V | 1P 110V | 1P 220V | ||||
| Frequency | 50/60Hz | 50/60Hz | 50/60Hz | 50/60Hz | ||||
| Welding Mode | MMA | TIG | MMA | TIG | MMA | TIG | MMA | TIG |
| Rated Input Power | 4.5KW | 2.7KW | 4.9KW | 3.0KW | 4.5KW | 2.7KW | 6.6KW | 4.1KW |
| Rated Input Current | 55.9A | 34.0A | 30.4A | 18.7A | 55.9A | 34.0A | 40.8A | 26.0A |
| Output Current Range | 10-140A | 10-150A | 10-140A | 10-190A | ||||
| Efficiency | Above 80% | Above 80% | Above 80% | Above 80% | ||||
| Duty Cycle (40°C 10min) | 60%140A, 100%108A | 60%150A, 100%116A | 60%140A, 100%108A | 60%190A, 100%147A | ||||
| Open Circuit Voltage | 56V | 56V | 56V | 56V | ||||
| N.W | 10.0KG | 10.0KG | 12.4KG | 12.4KG | ||||
| G.W | 11.5KG | 11.5KG | 13.6KG | 13.6KG | ||||
| Packing Dimension | 415×320×340mm | 415×320×340mm | 465×335×360mm | 465×335×360mm | ||||
(1) Ground Cable with Clamp (10’)
(1) WP #17 TIG Torch (14’)
(1) Instruction Manual
