3 IN 1 Battery Powered MIG/LIFT/TIG/MMA Welder 160A

MIG-360

Description:

MIG-360 is a professional battery-powered MIG/LIFT/TIG/MMA inverter welder with built-in 1382Wh LFP type of li-ion battery pack. Max output current is 160A, one single charge can burn up to 1.2kgs of 0.8mm flux core wire or 40 pieces of 2.5mm electrodes.

Inquiry Download

Specifications Features Applications

Battery Specifications
Battery type	LFP Lithium Ion battery cell
Battery voltage	DC 51.2V
Battery capacity	1382Wh
Battery cooling	Air (4 x automatic air fans)

Welding Specifications
Welding Process	MIG, LIFT TIG. MMA
Output current	10-160A
Suitable electrode diameter	1.6-4.0mm
Suitable MIG flux core wire	Dia 0.8-1.2mm
Weight of 0.8mm flux core wire	1.2kgs
Duty Cycle	35%

Charger Specifications
Charger voltage	AC 100-240V 50/60Hz
Charger output	57.6V 15A
Charging time	±1.8 hours
Charging cycles	3000 (capacity > 80%)

Working Temperatures
Operating temperature	-20°C up to 40°C
Charging temperature	0°C up to 30°C
Storage temperature	0°C up to 25°C

Dimensions and Weight
Dimensions (L x W x H)	575x214x362mm
Weight	23.9kg

Other
Ingress protection class	IP21 (indoor)
Warranty	12 months or 300 charging cycles. Whichever comes first.

Compatible with MIG, MMA, and TIG functions.

Buit-in 1382Wh LFP type of li-ion battery pack, cycle times of battery up to 3000 times, charging time only 1.8 hours.

Heavy-duty design, compatible with 1kg to 5kg wire spools and suitable for Ø0.8mm to Ø1.2mm flux-cored wire.

Semi-automatic wire feeding structure for smooth and efficient welding.

MlG parameters can be adjusted easily without professional welding skills.

The welding circuit is equipped with intelligent detection functions for anomalies, overheating, and undervoltage.

Intelligent digital control circuit for aesthetically pleasing weld formations.

12 months warranty

The Battery-powered MIG/LIFT/TIG/MMA Inverter Welder is a versatile welding tool designed for on-the-go and remote welding tasks. Its primary applications include outdoor construction, maintenance and repair, automotive work, and situations where access to mains power is limited. With its compact and portable design, it is ideal for professionals and DIY enthusiasts who require flexibility and reliability in welding operations.
