120A Battery Powered MMA Welder 9KG Only

AK-310

Description:

AK-310 is an extremely portable battery-powered MMA inverter welder with built-in 480Wh of li-ion battery pack. Max output current is 120A, one single charge can burn up to 13 pieces of 2.5mm electrodes or 6 pieces of 3.2mm electrodes.

Inquiry Download

Specifications Features Applications

Battery Specifications
Battery type	NCM Lithium Ion battery cell
Battery voltage	DC 51.2V
Battery capacity	480Wh
Battery cooling	Air (4 x automatic air fans)

Welding Specifications
Welding Process	MMA
Output current	10-120A
Suitable electrode diameter	1.6-3.25mm
Pieces 2.5mm electrode	13 pieces
Pieces 3.2mm electrode	6 pieces
Duty Cycle	35%

Charger Specifications
Charger voltage	AC 100-240V 50/60Hz
Charger output	57.6V 8A
Charging time	± 1.5 hours
Charging cycles	1,500 (capacity > 80%)

Working Temperatures
Operating temperature	-20°C up to 40°C
Charging temperature	0°C up to 30°C
Storage temperature	0°C up to 25°C

Dimensions and Weight
Dimensions (L x W x H)	355x180x310mm
Weight	9.0kg

Other
Ingress protection class	IP21 (indoor)
Warranty	12 months or 300 charging cycles. Whichever comes first.

Buit-in 480Wh NCM type of li-ion battery pack, cycle times of battery up to 1500 times, charging time only 1.5 hours.

Heavy-duty design, suitable electrode diameter from 2.5mm to 3.25mm, one single charge can burn up to 13 pieces of 2.5mm electrodes or 6 pieces of 3.2mm electrodes.

The welding circuit is equipped with intelligent detection functions for anomalies, overheating, and undervoltage.

Intelligent digital control circuit for aesthetically pleasing weld formations.

12 months warranty.

The Battery-powered MMA Inverter Welder is a versatile welding tool designed for on-the-go and remote welding tasks. Its primary applications include outdoor construction, maintenance and repair, automotive work, and situations where access to mains power is limited. With its compact and portable design, it is ideal for professionals and DIY enthusiasts who require flexibility and reliability in welding operations.
