Built-in Battery Powered Welder 150A

AK-330

Description:

Innovative, battery-powered welding equipment, ideal for those jobs where portability is essential and no power supply is available in the work area.

Inquiry

Specifications Features Applications

Battery Specifications
Battery type	Ternary Lithium Ion battery cell
Battery voltage	DC 48V
Battery capacity	962Wh
Battery cooling	Air (2 x automatic air fans)

Welding Specifications
Output current	10-150A
Suitable electrode diameter	1.6-3.2mm
Pieces 2.5mm electrode	23 pieces
Pieces 3.2mm electrode	11 pieces
Duty Cycle	100% 150A

Charger Specifications
Charger voltage	AC 100-240V 50/60Hz
Charger output	54.6V 8A
Charging time	± 2.5 hours
Charging cycles	800 (capacity > 80%)

Working Temperatures
Operating temperature	-20°C up to 40°C
Charging temperature	0°C up to 30°C
Storage temperature	0°C up to 25°C

Dimensions and Weight
Dimensions (L x W x H)	375x178x300mm
Weight	11.5kg

Other
Ingress protection class	IP21 (indoor)
Warranty	12 months or 300 charging cycles. Whichever comes first.

Built-in 962Wh li-ion battery pack, heavy duty design. 3.25mm electrode can weld up to 11 pieces,2.5mm electrode can weld up to 23 pieces.

Max output current 150A, duty cycle 100%.

International brand battery cells, BMS control, safe and reliable in quality.

Hot start & Arc Force functions

Easy to read battery level indicator

Intelligent ventilation system(eco fan)

CE approval

12 months warranty

AK-330 cordless welder are widely used in mining, construction, steel industry, service truck, agricultural, ships, as well as bridges, perfect for welding in remote locations, construction sites, and highly suitable for welding in electrically hazardous environment.
