Battery Powered Welding Generator 4000W With IP54 Protection Class

ES-560

Description:

The ES-560 is an advanced, eco-friendly, and powerful battery-powered welding generator, designed for professionals who need reliable welding performance on the go. With an output power of up to 4000W and an output voltage of 220V (110V optional) it offers the versatility to handle a wide range of welding tasks. Capable of delivering a 150A welding current, it is suitable for MMA and LIFT TIG welding processes. This generator operates with zero emissions, making it a sustainable choice for users who prioritize environmental impact Additionally, it is noise-free, maintenance-free, and easy to operate, providing a smooth and eficient experience for every welding project.

Inquiry

Specifications Features Applications

Power Specifications
Rated output voltage	AC 220V 50Hz
Socket specification	1 x EU type F (grounded) IP44, 1 x CEE type Socket 16A
Rated output power	Max. 4000W
Surge power	Max. 8000W
Overload protection	(20 A)

Battery Specifications
Battery type	Ternary Lithium Ion battery cell
Battery voltage	DC 48V
Battery capacity	5627 Wh
Battery cooling	Air (4 x automatic air fans)

Welding Specifications
Output current	10-150A
Suitable electrode diameter	1.6-4.0mm
Pieces 4.0mm electrode	61 pieces
Pieces 3.2mm electrode	99 pieces
Pieces 2.5mm electrode	200 pieces

Charger Specifications
Charger voltage	AC 200-240V 50/60Hz
Charger output	57.6V 30A
Charging time	±4.0 hours
Charging cycles	1500 (capacity > 80%)

Working Temperatures
Operating temperature	-20°C up to 40°C
Charging temperature	0°C up to 30°C
Storage temperature	0°C up to 25°C

Dimensions and Weight
Dimensions (L x W x H)	580x570x600mm
Weight	78kg

Other
Ingress protection class	IP54 (indoor)
Warranty	12 months or 300 charging cycles. Whichever comes first.

Battery Powered

Completely battery-powered system - no long power cords, heavy cables or generators necessary.

Heavy-duty Design

Battery capacity up to 5627Wh, max power output 4000W.

Welding Function MMA & LIFT TIG

Max output current 150A, suitable for electrode diameter 2.5mm-4.0mm.

Safety& Reliability

Internal lithium battery cells we are working with CATL, CATL battery cells widely used in car industry, main customer including many famous brands such as BMW, Volkswagon, Toyota and Audi. Battery power system matters a lot in battery welder, we tried many different suppliers and finally we found CATL is the best choice for our welder.

Eco-Friendly & Noise Free

Compared with traditional generators, ES-560 is surely eco-friendly and noise free and emission free. Besides, comparing the cost of gasoline and electricity, power station is nice choice.

Intelligent

Battery power indicator Under-voltage, overload, over-heating and over-discharge protection

Quick Charging

Equipped with high efficiency battery charger, charging time 4.0 hours only.

Warranty

All of our products, warranty period is 12 months, during warranty period, if any spare parts problem, we will afford the courier and spare cost.

Outdoor Welding:

Perfect for construction sites, maintenance tasks, and field repairs, where mobility and power are needed without traditional generators.

Emergency Welding:

Provides reliable welding power during emergencies or power outages, ideal for mobile repair services or urgent repairs.

Off-Grid and Remote Locations:

Perfect for off-grid projects,remote construction sites, and outdoor work that requires a portable and eco-frendly welding solution.

Automotive and Metalwork:

Suitable for smal workshops, automotive repairs, and metalworking projects that need aversatile welding power source.

This versatile and efficient welding generator ensures that you have reliable power wherever and whenever you need it, while maintaining a clean, quiet, and eco-friendly environment.
