Multi-function Battery Powered Plasma Welding & Cutting System

ES-8024

Description:

This battery-powered air plasma cutter combines MMA, CUT, and TIG functions in one versatile machine. Equipped witha 24115Wh LFP lithium battery, it can also deliver AC 220V / 4000W power output for external devices. The cutter provides a stable output current of 30-240A and a cutting capacity of up to 25 mm, making it ideal for portable, off-grid welding and cutting applications.

Inquiry

Specifications Features Applications

Power Specifications
Rated output voltage	AC 220V 50Hz
Socket specification	1 x EU type F (grounded) IP44, 2 x CEE type Socket 16A
Rated output power	Max. 4000W
Surge power	Max. 8000W
Overload protection	(20 A)

Battery Specifications
Battery type	Lithium Iron phosphate battery cell
Battery voltage	DC 72V
Battery capacity	24115 Wh
Battery cooling	Air (4 x automatic air fans)

Welding Specifications
Output current	30-240A
Suitable electrode diameter	1.6-5.0mm
Output cutting current	20-80A
Cutting capacity	Up to 25mm
Plasma gas	Compressed gas
Cutting torch	Air cooling

Charger Specifications
Charger voltage	AC 200-240V 50/60Hz
Charger output	84.5V 30A
Charging time	±6.5 hours
Charging cycles	3000 (capacity > 80%)

Working Temperatures
Operating temperature	-20°C up to 40°C
Charging temperature	0°C up to 30°C
Storage temperature	0°C up to 25°C

Dimensions and Weight
Dimensions (L x W x H)	1211x620x975mm
Weight	312kg

Other
Ingress protection class	IP54 (indoor)
Warranty	12 months or 300 charging cycles. Whichever comes first.

Multi-Function

Combines MMA welding, TIG welding, and plasma cutting in a single machine.

High-Capacity Battery

24115 Wh LFP lithium battery ensures long working hours and reliable power.

Portable & Off-grid

Ideal for remote locations without AC power.

Power Output Capability

Provides AC 220V / 4000W power supply for external tools and devices.

Wide Cutting Range

Cutting capacity up to 25 mm with adjustable output current from 30-240A

Stable Performance

Designed for consistent, high-quality welding and cutting results.

ECO-friendly & Noise Free

Compared with traditional generators, ES-8024 is surely eco-friendly and noise free. Besides, comparing the cost of gasoline and electricity. power station is nice choice.

Intelligent

Battery power indicator Under-voltage, over-heating alarm

Construction & Fabrication: Ideal for on-site cutting, welding, and metal fabrication tasks.

Maintenance & Repair: Perfect for repair work in factories, workshops, and remote locations.

Off-Grid & Portable Operations: Supports work in locations without AC power thanks to its high-capacity LFP battery.

Industrial & DlY Projects: Suitable for professional industrial use as well as hobbyist or DlY metal working projects.

Emergency Power Supply: Can provide AC 220V/ 4000W power to tools and devices when needed.
